Pneumatic Grain Suction Machine

Brand :Cafu

Product origin :China

The pneumatic unloader is widely used in warehouses, terminals and processing plants for the transfer and loading and unloading of bulk granular materials, such as wheat, rice, soybeans, corn, rapeseed, feed, granular fertilizers, plastics and other materials, especially for the in and out of warehouses, transfer, loading and unloading of materials. As well as the local heat, high temperature, disease and insect mold operations on the surface of the grain bin.

▍Pneumatic grain suction machine

unloader

CAFU environmental protection intelligent Pneumatic Unloader is a new type of agricultural machinery that carries out bulk conveying operation of grain through pneumatic conveying. It can convey materials horizontally, inclined and vertically by using pipe layout. With independent walking function, it is easy to move. Remote control operation, simple and convenient operation, single machine can complete the conveying task independently.

The main purpose of the Pneumatic Unloader is to suck and unload bulk granular materials (such as wheat, rice, corn, rapeseed, soybeans, cottonseed, feed, etc.), and is suitable for mechanized operations such as loading, unloading, replenishing, discharging, turning, and reversing in farms, docks, stations, warehouses, etc.

The Pneumatic Unloader equipment is available in models ranging from 10 tons to 100 tons depending on the output.

pneumatic grain unloader

Mobile grain suction machine technical parameters

Item		Unit	Specification					Remarks
Item		Unit	D20	D30	D50	D75	D100	Remarks
1	Delivery capacity	t/h	20	30	50	75	100
2	Overall power	kw	18	29.5	54	65	86
3	Noise	dB(A)	85	85	85	85	85
4	Exhaust dust content	mg/m3	50	50	50	50	50
5	Horizontal length of large arm	m	5	6	7	8	9
6	Vertical length of large arm	m	2	3	3	3	5
7	Large arm horizontal telescoping	m	2	2	2	3	3
8	External dimensions	mm	300017003500	380019003660	420021003800	400021003860	450022003950

▍Port grain suction machine

Port grain suction machine technical parameters

Item		Unit	Specification					Remarks
Item		Unit	100	200	300	400	600	Remarks
1	Delivery capacity	t/h	100	200	300	400	600
2	Overall power	kw	125	217.5	320	200*2+35	300*2+40
3	Horizontal length of large arm	m	10.5	15	20	25	30
4	Large arm horizontal telescoping	m	2	3	4	4	5
5	Applicable ship type	kw.h/t	3000	10000	20000	30000	50000	Customizable

For a detailed description of the pneumatic grain suction machine, please download the product brochure for review.
